From the very beginning in 1969, All-Fill Inc. and Auger Fabrication offered two different set ups that became commonly referred to as small & large tooling. Both styles involved many parts and came with limitations. As time passed, the name associated with the small tooling became “old style small” and the large tooling “old style large.”

“Old Style-Small”“Old Style-Large”

2.5” opening hopper 3.25” opening hopper

7 ¼” & 13 ¼” long auger shaft6 5/8” & 10 5/8” long auger shaft

Augers: ½” stem with 3 1/16” cross pin Augers: 5/8” stem with 1/4” cross pin

Standard Auger Lengths: 10” & 18” Standard Auger Lengths: 13” & 18”

Standard Funnel Lengths: 4 9/16” & 12 9/16” Standard Funnel Lengths: 5 9/16” & 12 9/16”

Funnel Hub Diameter: 3.5” Funnel Hub Diameter: 4”

Only for #4 through #32 auger & funnel Only for #4 through #32 augers & funnels

In 1997 All-Fill introduced “Universal Style tooling” which eliminated & consolidated the aforementioned filling accessories.  This design change allowed every filling machine to accept every size of standard filling accessory. Now, all filling accessories consist of the following:

“Universal Style Tooling”

3.25” opening hopper

6 5/8” & 10 5/8” long auger shaft

Augers: 5/8” stem with 1/4” cross pin

Standard Auger Lengths: 13 1/8” & 20 1/8”

Standard Funnel Lengths: 5 9/16” & 12 9/16”

Funnel Hub Diameter: 4”

For more information regarding this post or for interest in purchasing filling accessories, please contact your local All-Fill or Auger Fabrication salesperson.  As always, product tests are free of charge in our fully stocked test lab located in Exton, PA.  We look forward to seeing you soon and thank you for your continued interest in our fine family of companies.
